C6670-0020 | Control cabinet industrial server
please contact us
The C6670-0020 industrial server is equipped with two Intel® Xeon® scalable processors from the 5th generation with up to 32 cores per CPU and a memory of 128 to 1,024 GB D……
The C6670-0020 industrial server is equipped with two Intel® Xeon® scalable processors from the 5th generation with up to 32 cores per CPU and a memory of 128 to 1,024 GB DDR5 RAM. This makes it ideal for machine controls, for example with the XPlanar planar motor system. The C6670-0020 can be ordered with M.2 NVMe™ SSDs up to 640 GB and up to two hard disks with 1, 2, or 4 TB. It also features five free PCIe® slots for EtherCAT or Ethernet fieldbus cards or similar.
Industrial design
All connections of the industrial server face upwards, so that the connecting cables can be taken directly to the wiring channel. The side walls are completely passive, and allow the industrial server to be fitted immediately next to other control cabinet devices.
Highest data availability and data security
An NVMe™ M.2 SSD ensures fast booting and data access. The C6670 also contains two removable hard disk frames, which can form a RAID 1 system with two mirrored hard disks for the secure storage of large amounts of data.
Flexible expansion options
Drives, memory and plug-in cards are easily accessible. The C6670 is supplied with a 100 to 240 V AC full-range power supply unit. A multi-DVD drive can be installed. Hold-down brackets for the plug-in cards ensure insensitivity to shocks and vibrations. A type plate is located on the top of the front cover, giving detailed information about the server configuration.
Advantage at the very core: the Beckhoff Industrial PCs
Beckhoff is a pioneer in PC-based automation technology and has been developing and producing its own PC hardware since 1986. The technology know-how that has grown over the past decades is incorporated today into all Beckhoff Industrial PCs. Their principle feature is the use of state-of-the-art components and processors of the highest performance class. Combined with a high in-house production depth, including proprietary motherboard production, long-term component availability, extremely flexible configuration and customer-specific adaptations, Beckhoff presents itself today as one of the world’s leading Industrial PC manufacturers.
