EL1008 | EtherCAT Terminal, 8-channel digital input, 24 V DC, 3 ms
please contact us
The EL1008 digital input terminal acquires the binary 24 V control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. Eac……
The EL1008 digital input terminal acquires the binary 24 V control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. Each EtherCAT Terminal has eight channels that indicate their signal state via light emitting diodes.
Special features:
- input specification type 1/3
- no bouncing due to mechanical switches thanks to 3 ms input filter
